Precision matthews PM-833TV

32
PM-833TV 4-13-21V1.indd Copyright © 2021 Quality Machine Tools, LLC
TABLE, COLUMN & BASE COMPONENTS Fig 1
Ref Description Part
37 Screw: skt head, M8 x 16 Z7602
38 Ball handle Z7603
39 Grip Z7604
40 Z7605
41 Z7606
42 Screw, set: M5 x 5 Z7607
43 X/Y Handwheel assy, with graduated dial Z7608
44 Ball bearing Z7609
45 Screw: skt head, M6 x 16 Z7610
46 Bearing ange Z7611
47 Table Z7612
48 Key Z7613
49 X-axis leadscrew Z7614
50 Screw: skt head, M8 x 20 Z7615
51 X-axis leadscrew nut Z7616
52 Limit stop component Z7617
53 Limit stop component Z7618
54 Limit stop component Z7619
55 Bearing ange Z7620
56 Saddle Z7621
57 Z7622
58 Z7623
59 Screw: skt head, M8 x 16 Z7624
60 Stop casting Z7625
61 Y-axis gib Z7626
62 Y-axis leadscrew nut Z7627
63 Y-axis clamp lever Z7628
64 Table (X-axis) gib Z7629
65 Y-axis leadscrew Z7630
66 Z7631
67 Z7632
68 Z7633
69 Z7634
70 Z7635
71 Stand & tray assembly Z7636
Ref Description Part
1 Base casting Z7566
2 Lock washer Z7567
3 Screw: hex head Z7568
4 Column casting Z7569
5 Z-axis gib Z7570
6 Gib adjust screw Z7571
7 Headstock support casting (Z-axis saddle) Z7572
8 Flange nut Z7573
9 Screw: skt head, M8 x 20 Z7574
10 Clamp lever Z7575
11 Z-axis leadscrew Z7576
12 Flange Z7577
13 Screw: skt head, M6 x 16 Z7578
14 Ball bearing 6002 Z: 15 x 32 x 9 Z7579
15 Taper pin Z7580
16 Collar Z7581
17 Z-axis leadscrew nut Z7582
18 Pleated way cover Z7583
19 Screw: skt head, M5 x 8 Z7584
20 Ball bearing 6002 Z: 15 x 32 x 9 Z7585
21 Screw: skt head, M6 x 16 Z7586
22 Flange Z7587
23 Bracket Z7588
24 Worm wheel Z7589
25 Washer Z7590
26 Screw: skt head, M8 x 16 Z7591
27 T-slot bolt (1/2" x 50L) Z7592
28 Z7593
29 Worm shaft Z7594
30 Key Z7595
31 Ball bearing 6204 Z: 20 x 47 x 14 Z7596
32 Flange Z7597
33 Z7598
34 Collar Z7599
35 Graduated dial, Z axis Z7600
36 Z7601
