Precision Power PPI4240 - Power Output and Crossover Settings; PPI Model Power Output; Crossover Frequency and Type; Recommended Fuse Ratings

2
PPI4240 30W x 4 Channels @ 4 Ohms
60W x 4 Channels @ 2 Ohms
120W x 2 Channels @ 4 Ohms Bridged
PPI5440 30W x 4 Channels @ 4 Ohms
+ 120W x 1 Channel @ 4 Ohms
60W x 4 Channels @ 2 Ohms
+ 200W x 1 Channel @ 2 Ohms
120W x 2 Channels @ 4 Ohms Bridged
+ 120W x 1 Channel @ 4 Ohms
PPI4240 Front Variable 12db/Octave FULL/HPF/LPF 20-5kHz
Rear Variable 12db/Octave FULL/HPF/LPF 20-5kHz
Selectable FULL/HPF/LPF RCA Output
PPI5440 Front Variable 12db/Octave FULL/HPF/LPF 20-5kHz
Rear Variable 12db/Octave FULL/HPF/LPF 20-5kHz
Sub Variable 12db/Octave FULL/HPF/LPF 20-500Hz
PPI4240 Maximum Fuse Rating: 40 Amp (20 x 2)
PPI5440 Maximum Fuse Rating: 60 Amp (30 x 2)
