Precor C966i Owner's Manual

page 17
COMMERCIAL PRODUCTS DIVISION
Diagram 14 Replace the
hood and
secure it.
Buttonhead
screws (A) with
washers (B)
secure the front
of the hood.
Hood
13. Tighten all mounting screws with the hex keys provided. Diagram 15.
Start at the front of the treadmill with the four screws that attach the upright
supports to the front panel. Tightening these screws first helps pull the rest of
the treadmill’s parts into alignment. Then, proceed with tightening the four
sockethead screws (D) that secure the upright supports, the four console
assembly screws (A), the handrail assembly screws (A) and (C), and the hood
screws (shown in Diagram 14).
Diagram 15 Secure the
fasteners and
replace the
hood.
Alternately
tighten the four
front panel
screws.
Alternately tighten
the four screws
that secure the
display console.
Alternately
tighten four
side upright
screws.
12. Replace the hood. Diagram 14. Reposition the hood on the treadmill. Remove
four buttonhead screws (A) with washers (B) from the hardware kit. Two
buttonhead screws and washers are placed through the front panel and the
remaining two screws and washers are used to secure the hood to the siderail.
Tighten the screws using the appropriate hex keys.
Buttonhead
screws (A) with
washers (B)
secure the hood
to the siderail.
1
2
1
2
3

Precor C966i Specifications

Power and Motor

motor power	4.0 hp continuous duty
power requirements 120v	120 v @ 50/60Hz 20 Amps
power requirements 240v	240v @ 50/60Hz 20 Amps

Performance

speed range	0.5 to 16 mph (1 to 26 kph)
incline range	-3% to 15% grade

Weight and Dimensions

length	86 inches (218 cm)
width with handrails	37 inches (93 cm)
width without handrails	34 inches (86 cm)
height	59 inches (150 cm)
weight	375 lbs (170 kg)
shipping weight	470 lbs (213 kg)
running surface	60 inches x 20 inches (153 cm x 51 cm)
