Precor C966i Owner's Manual

page 18
COMMERCIAL PRODUCTS DIVISION
Diagram 17
21
Raise or
lower the
deck.
14. Level the unit. Diagram 16. Check to make sure that the running deck is level
by taking the following steps:
a. Use a bubble level as shown in Diagram 16 to verify that the running deck
is level. If the treadmill is placed on a slightly, uneven surface, adjusting the
rear feet can help, but will not compensate for extremely uneven surfaces.
Important: If you need to make adjustments, adjust one rear foot at a time.
Do not use the rear foot to raise or lower the unit more than ¾-inches.
Adjustable
rear foot
Hand holds
on rear end
caps
Diagram 16
Adjust the level
of the treadmill.
Running belt
Bubble level
Adjustable rear
foot
b. Adjust the rear feet. Diagram 17. To raise the rear deck, situate yourself
next to the adjustable rear foot. Ask an assistant to lift the rear of the
treadmill slightly while you turn the adjustable rear foot clockwise. Turning
the rear foot counterclockwise lowers the unit.
c. Check the level of the unit after each adjustment. Make adjustments to
the rear feet so that both carry an equal amount of the treadmill’s weight
and the load placed upon it.
Important: If the load is not equally compensated, the user will feel
excessive vibration or movement at the display console.

Precor C966i Specifications

Power and Motor

motor power	4.0 hp continuous duty
power requirements 120v	120 v @ 50/60Hz 20 Amps
power requirements 240v	240v @ 50/60Hz 20 Amps

Performance

speed range	0.5 to 16 mph (1 to 26 kph)
incline range	-3% to 15% grade

Weight and Dimensions

length	86 inches (218 cm)
width with handrails	37 inches (93 cm)
width without handrails	34 inches (86 cm)
height	59 inches (150 cm)
weight	375 lbs (170 kg)
shipping weight	470 lbs (213 kg)
running surface	60 inches x 20 inches (153 cm x 51 cm)
