Precor C966i Owner's Manual

page 19
COMMERCIAL PRODUCTS DIVISION
CAUTION: To make sure the power cord is not pinched or damaged by the
incline lift, attach the power cord to the base frame using the clips provided.
15. Attach the power cord clip. Diagram 18, #1. Remove a cord clip from the
Hardware kit. Wrap it around the power cord near its receptacle and clamp it shut.
16. Insert the clip into the base frame. Diagram 18, #2. Insert the serrated portion of
the cord clip into the hole located under the front panel on the base frame.
17. Install the remaining cord clips. Diagram 19. Wrap at least two more cord
clips around the power cord and insert the clips into the holes found in the
frame beneath the side rail. The holes are spaced a foot apart (approximately
31 cm) along the length of the side rail.
18. Plug the power cord into a dedicated, grounded circuit. Place the clips
as needed along the length of the power cord while you route it to the power
outlet.
Important: Check the length of the the power cord to make sure that it
cannot get pinched or damaged by the incline lift movement.
CAUTION: The treadmill requires a dedicated, grounded circuit. A 20 amp
dedicated circuit is recommended. Make sure that no other product or
machine uses the same circuit as the treadmill. Refer to Grounding
Instructions on page 3.
Diagram 18 Attach the power
cord clip.
2
1
Cord clip
Power cord
Front panel
Incline lift
Diagram 19 Install the
remaining
cord clips.
Side rail
Power cord

Precor C966i Specifications

Power and Motor

motor power	4.0 hp continuous duty
power requirements 120v	120 v @ 50/60Hz 20 Amps
power requirements 240v	240v @ 50/60Hz 20 Amps

Performance

speed range	0.5 to 16 mph (1 to 26 kph)
incline range	-3% to 15% grade

Weight and Dimensions

length	86 inches (218 cm)
width with handrails	37 inches (93 cm)
width without handrails	34 inches (86 cm)
height	59 inches (150 cm)
weight	375 lbs (170 kg)
shipping weight	470 lbs (213 kg)
running surface	60 inches x 20 inches (153 cm x 51 cm)
