Attach the Feet and Foot Covers
To Attach the Adjustable Foot:
1. Align the adjustable foot with the hole built into the cylindrical leg.
2. Screw the adjustable foot into the leg until the machine sits level on
the floor.
Caution: To prevent damage to the adjustable foot, screw it all the way
into the frame before moving equipment.
Figure 1: Adjustable foot attachment
The following graphic shows the location of the adjustable foot.
Figure 2: Adjustable foot and foot cover attachment locations
Shoulder Press Assembly and Delivery Guide: Attach the Feet and Foot Covers
3
