FTS Glide Assembly and Maintenance Guide
page 17
1 2 3 4 5 6
Step 4. Attach Handles and Accessories
4. Attach Handles and
Accessories
A. Install a blue handle on each Pulley Assembly
using
one 4mm socket head screw
Wrench tighten with a hex key.
Note: To adjust the outside pulley location, lift the
blue handle and slide it to the desired location.
B. Attach the two Soft Handles or a Soft Ankle Strap to
the end of the cable using a Spring Clip.
This completes the assembly of your FTS Glide
Strength-Training Fitness Equipment.
A
B
Install the Soft Handle or
Soft Ankle Strap.
Pulley Assembly
1 - 4mm socket head screw
on each Pulley Assembly
Spring
Clip
Soft
Handle

Precor FTS Glide Specifications

Weight and Dimensions

length	48.5 inches (123 cm)
height	85 inches (216 cm)
width	53 inches (135 cm)
