Precor P30 Console - Using the Treadmill Safety Clip

Introducing Users to the P30 Console 39
Using the Treadmill Safety Clip
The treadmill is equipped with three different stop functions,
which behave as follows:
If the user … Then the
treadmill
belt …
And the console …
Pulls on the lanyard
attached to the safety
clip and trips the
restart switch
Slows to a
stop
Shows the words PUSH THE
RESET SWITCH. On some
console models, an arrow
points toward the Restart
switch.
Presses down on the
red STOP button
Slows to a
stop
Shows that the exercise
workout is paused.
Steps off of the
running belt for a
preset amount of
time
Slows to a
stop
Shows that the exercise
workout is paused.
The restart switch and the red STOP button are located just
below the console, as shown in the following figure. When the
switch is tripped, the button pops up. The treadmill does not
operate until the button is returned to its normal position.
Figure 6: Restart switch
