1Cable Installation Vefication
About
The console to base calbles installation should be routed in a very specific order and in a very
specific path to avoid damage to the cables. This section provides a systematic process to
verify that the cables have been correctly routed through the console. Operating and functional
issues could occur if the cables have been improperly routed during the installation process. If
you have a functionality problem with a P82 console, verifying that the interface cables were
routed correctly prior to any other troubleshooting could save you time and frustration.
Equipment Base Cable Installation:
To verify the equipment base cable routing, refer to the installation assembly guide shipped
with the specific equipment base type (TRM, EFX, AMT, RBK, and UBK).
Power cable installation:
The P82 input power is provided by a separate 12 Vdc power supply.
Treadmill bases
The power supply input power cable is is connected to the LPCA line filter and is mounted on
the front frame using velcro strips. The supply output power cable is routed through the con-
sole frame support to the console. The earth ground is connected through the power supply.
All other self-power equipment bases
For ALL other self powered units, unless specifically stated, the power supply brick must be
placed outside of the equipment covers, excessive heat can camage the power supply. Ttyp-
ically the power supply brick is placed in a cable management “Tee” connector or other cus-
tomer supplied cable management.
Make sure that the power supply ground lug is connected (grounded) to the equipment frame
with bare metal-to-metal contact.
P80 Armor Cable Installation
In the back of the P80 console is a large black steel support, called the Armor. At the bottom of
the unit’s mounting plate there is a hook that holds the console in place, leaving your hands
free to perform the cable routing steps. Remove the 4 console mounting screws and tilt the
console forward, allowing the hook to support the console. Verify the cable routing against the
following steps. Cables should be routed through the center of the armor and out specific side
openings in the armor. The specific order and path that these cables are routed allow them to
(Undefined variable: EFX800-16Base.ServiceManualTitle) 11
