> opens
Diagnostic tests and hardware calibration
page.
Navigating the Service Software Menus
Console hardkeys and softkeys used to navigate the service software menus.
Standard, P10, P20, & P30 consoles:
The service software is organized in a sequential top-menu sub-menu architecture with instruc-
tions shown on the workout information display. Use the console keys to navigate and select
service mode operations.
CONSOLE KEY FUNCTION/DESCRIPTION
Up/Down Moves up and down through the current menu.
OK Selects current menu item or confirms setting.
BACK/CLEAR
• Returns to the previous menu level without saving changes.
• Hold Back to exit the Display test.
PAUSE • Exits service mode
• Press and hold PAUSE will open the Error Log or show the "Stuck
Key" message when there are no logged errors.
P80 series consoles:
The P80 uses the touch-screen to view, navigate, and perform the diagnostic tests. Follow on-
screen prompts to access and complete tests.
Hardware Validation - Diagnostic Tests (51765761)
Service Access Code: 5,1,7,6,5,7,6,1 (see "Service Access Codes" on page20)
The set of available diagnostic tests will vary based on console model. Select console model to
view the available diagnostic tests.
Standard, P10, P20, & P30 consoles:
DIAGNOSTIC
TEST
TEST DESCRIPTION
Display Test
Tests the console LEDs. Successively press the OK key to verify each group
of LEDs and verify that all LED's illuminate. Press Back to exit the test.
Keypad Test
An illuminated LED map of the function keys will be shown. Press each indi-
vidual key and verify that the corresponding LED extinguishes. Press and hold
BACK to exit the test
PVS Key Test
Not used, OEM test.
Heart Rate Test
Tests the unfiltered, filtered, and pulse values. Grasp the grips to test the hand
held heart rate. Use a Polar heart rate simulator to test the wireless heart rate.
Press the back button to exit this test.
P82 Console 22
3 Standard Service Software
Navigating the Service Software Menus
