outlet except for tradmills which are powered from the treadmill line filter output.
Dedicated Branch Circuit
For consoles powered from facility AC power outlets, a maximum of 10 consoles can be con-
nected to one 20-amp dedicated branch circuit. If the branch circuit has any other devices con-
nected, the number of P82 consoles must be reduced by the wattage of the other devices.
Input Power
12 VDC, 60 W external power supply operated from either:
l Facility AC line power with earth ground connected through the supply.
l Treadmill units are powered from the LPCA input power after the line filter.
Earth Ground
For operator safety and to minimize electrostatic discharge conditions, for AC powered units,
the earth ground must be connected through the power supply.
