©2019 Precor Inc. | Rear Delt/Pec Fly RSL 505 | Assembly Guide
4
Part # Name Quantity Part # Name Quantity
Main frame 1 End caps 2
Left arm assembly 1 Shoulder bolts 2
Right arm assembly 1 Shafts, 8 mm x 17 mm 2
Lower cross brace 1 Washer, rubber, black 1
Seat assembly 1 Washer, silver, 13.5 mm ID x 35 mm OD 1
Roller assembly 1 Washers, domed, silver 2
Shaft 1 Weight plates 10 lb (4.5 kg) 23
Gas spring 1 Roller adjustment tool (attached to Seat assembly) 1
Bumpers 4 Retaining rings, 3/4-inch 2
Weight stack spacer, 3-inch 1 Socket head cap screws (SHCS) M12 x 130 mm 2
Add-on weight 5 lb (2.2 kg) 1 Socket head cap screws (SHCS) M12 x 125 mm 2
Weight stack tower frame 1 Socket head cap screws (SHCS) M12 x 35 mm 4
Kick plate 1 Button head cap screws (BHCS) M10 x 125 mm 2
Add-on weight handle 1 Socket head cap screws (SHCS) M10 x 65 mm 2
Top plate assembly 1 Socket head cap screws (SHCS) M10 x 40 mm 2
Shroud, crown 1 Button head cap screw (BHCS) M6 x 15 mm 1
Guide rods 2 Hex head screws 5/16-inch x 1½-inch 4
Guide rod with cap 1 Button head cap screws (BHCS) 5/16-inch x 1½-inch 4
Add-on weight spacer, 5-inch 1 Retaining rings, 8 mm 2
Shroud, rear middle 1 Washers, 13 mm 8
Shroud, rear lower 1 Washers, 11 mm 6
Shroud, rear upper 1 Washers, 9 mm 8
Top tray 1 Nylon lock nuts, M12 2
Shroud, front middle (left and right) 2 Nylon lock nuts, M10 2
Shroud, front lower 1 Weight labels 1
Shroud, front upper placard 1
Shroud, lower pulley cover 1
Chest/back pad 1
Seat pad 1
1
10
11
12
13
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
3
30
31
32
33
34
35
36
37
39
4
40
42
43
44
45
46
47
48
49
6
7
8
9
2
5
14
Parts List
38
41
50
51
52
53
54
5
