For technical questions, please call 1-888-866-5797.
ITEM 62523
Table of Contents
Specifications ............................................. 2
Safety ......................................................... 3
Setup .......................................................... 7
Operation .................................................... 8
Maintenance .............................................. 13
Troubleshooting ......................................... 18
Parts List and Diagram .............................. 20
Warranties ................................................. 22
Specifications
Generator
Output
120VAC, 60Hz, 13.3A, 1 Phase
12VDC, 8A (nominal)
1600W Running
2000W Peak
Receptacles
2x NEMA #5-20 (3-prong, 120VAC)
1x 12VDC Two Prong Outlet
Displacement 79.7cc
Compression Ratio 8.7:1
Engine Type
Horizontal Single Cylinder
4-stroke, OHV
Cooling System Forced air cooled
Fuel
Type
87+ octane, stabilizer-treated
unleaded gasoline
Capacity 1 Gallon
Engine Oil
Type SAE 10W-40
Capacity 13 fl. oz.
Run Time @ 50% Load
with full tank
6 hr.
Sound Level at 23 feet, 50% load 66 dB
Bore x Stroke 48.6mm x 43mm
Spark Plug
Type A5RTC (Torch) or equivalent
Gap 0.023" - 0.027"
Valve Clearance
Intake 0.004" - 0.006"
Exhaust 0.004" - 0.006"
Engine Speed 4600 RPM
The emissions control system for this Engine is warranted for standards set by the
U.S. Environmental Protection Agency and by the California Air Resources Board (also known as CARB).
For warranty information, refer to the last pages of this manual.
