Page 20
For technical questions, please call 1-888-866-5797.
ITEM 62523
SAFETY OPERATION MAINTENANCESETUP
Part Description Qty
1 Engine 1
2 Screw, Cross Groove Pan 5
3 Cap 1
4 Muffler Cover 1
5 Tube, Fuel 1
6 Bolt 1
7 Tank, Fuel 1
8 Fuel Filter 1
9 Cover, Fuel Tank 1
10 Clamp, Oil Seal 1
11 Fuel Gauge 1
12 Bush 2
13 Element, Strainer 1
14 Cover, Muffler Side 1
15 Washer and Screw 6
16 Jaw Nut 6
17 Cushion, Joint Rubber 1
18 Clip, Spring 5
19 Cover, Right 1
20 Shell, Right 1
21 Shell, Left 1
22 Cover, Left 1
23 Decoration Cover, Right 1
24 Washer and Screw 9
25 Semi-Round Bolt 6
26 Square Nut 6
27 Sleeve, Fuel Tank Rubber 4
28 Rubber Cushion 2
29 Sleeve, Oil Fill 1
30 Jacket, Rubber 1
31 Opening, Oil Level View 1
32 Jacket, Rubber 1
33 Decoration Cover, Left 1
34 Guide, Starting Rope 1
Part Description Qty
35 Washer and Screw 1
36 Sleeve, Cable Handle Outer 1
37 Core, Cable Handle 1
38 Handle, Recoil Start Cable 1
39 Cross Screw 1
40 Plate, Bottom 1
41 Bolt 4
42 Seat, Frame 2
43 Seat, Frame 2
44 Nut 4
45 Nut 8
46 Seat, Frame 4
47 Bolt 8
48 Bracket, Cushion Rubber 1
49 Bracket, Cushion Rubber 1
50 Support, Invertor 1
51 Invertor 1
52 Rectifier Bridge 1
53 Cross Screw 1
54 Sleeve, Fuel Tank 1
55 Sleeve, Fuel Tank 1
56 Bolt 3
57 Indicator, Overload 1
58 Indicator, Output 2
59 Switch, Idle 1
60 Parallel Socket 2
61 Grounding Terminal 1
62 Reset Button 1
63 120 Volt Duplex Receptacle 1
64 Circuit Breaker 20A 1 Pole 1
65 Socket Subassembly, DC 1
66 Panel, Control, Asm. 1
67 Band 2
68 Nut 4
Part Description Qty
69 Seat, Panel 1
70 Cross Screw 4
71 Bolt 1
72 Control Box, Capstan 1
73 Cross Screw 1
74 Knob 1
75 Handle, Choke 1
76 Cover Plate 1
77 Block, Choke Cable Stopper 1
78 Ball, Steel 1
79 Spring, Stopper Adjusting 1
80 Switch, Stop Engine 1
81 Bracket, Fuel Cock 1
82 Cross Coiled Screw 2
83 Cock Asm., Fuel 1
84 Nut 1
85 Tube, Fuel 1
86 Tube, Fuel 1
87 Collar 2
88 Collar 1
89 Collar 1
90 Knob, Limited Position 1
91 Bolt 5
92 Shroud, Motor 1
93 Stator 1
94 Rotor 1
95 Impeller 1
96 Bolt 2
97 Pin 2
98 Bolt 2
99 Nut 1
100 Motor Asm. 1
101 Screw 4
102 Washer and Screw 4
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LISTS AND ASSEMBLY
DIAGRAMS IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE
OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED
TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR
EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY
CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK
AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT
PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List and Diagram
Parts List
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
