SDI-JC-22D2 rev. 11-1-21 page 21 of 22
Full Size Cutout Template
3.61
7.65
Edge of
Faceplate
(outside of panel)
Mounting
Bracket
(inside of panel)
JC-30D2
Panel Cutout
