2 INSTALLATION AND SETUP
15
Plug a microphone into channel one and turn on 48V phantom power if needed for the
microphone. Turn up the channel 1 trim control on the front panel of the FIREBOX
while speaking into the microphone. You should see the input meter in the Cubase LE
track info react to your speaking. Adjust trim so that the input level is at its maximum
without clipping.
Connect a set of headphones to the FIREBOX headphone output.
Click the monitor button in Cubase LE for Audio 01 to arm the track’s monitoring.
PreSonus has also included a Cubase LE session file template on the internet at
www.presonus.com/FIREBOX.html
Note that online help available for Cubase LE by pressing F1 or visiting
www.steinberg.net
