50
7
7.1
Technical Information
Specifications
Quantum 2626
Owner’sManual
Headphone Outputs
Type ¼”TRS Female, Stereo,Unbalanced, x2
MaximumOutputLevel 175 mW/channel (56Ω load)
Frequency Response 20 Hz to 20 kHz (±0.5 dB, 48 kHz)
Dynamic Range > 110 dB (A-wtd)
Total Harmonic Distortion < 0.03% (1 kHz)
Headphone Impedance(working range) 16Ω to 300Ω
Crosstalk
Input to Input < -110 dB
Output toOutput < -115 dB
InputtoOutput < -120 dB
Signal Level LED
Clip -0.5 dBFS
Signal -50 dBFS
Digital Audio
Connection Type Thunderbolt 3
ADCDynamicRange 115 dB (A-wtd)
DACDynamic Range 115 dB (A-wtd)
BitDepth 24 bits
Internally SupportedSample Rates 44.1, 48, 88.2, 96, 176.4, 192 kHz
Clock
Jitter < 70 ps RMS (20 Hz – 20 kHz)
Jitter Attenuation >60 dB(1 nsin => 1 ps out)
Power
12 VDC, 5A, external power supply
Clock
Jitter < 70ps RMS (20 Hz – 20 kHz)
Jitter Attenuation >60 dB (1 ns in => 1 ps out)
Physical
Height 1.75”(44.45 mm)
width: 19”(482.6 mm)
Depth 7” (177.8 mm)
Weight: 6 lbs (2.72 kg)
