Technical Information
Studio 24c
5 Technical Information 技术信息
5.1 Specifications 规格参数
5.1 Specifications
Owner’s Manual
General
Sample Rates 样本率 44.1, 48, 88.2, 96, 176.4, or 192 kHz
ConverterResolution 转换器分辨率 24 bit
ConverterDynamic Range 转换器动态范围 108 dB
ConverterDynamic Range 转换器动态范围 108 dB
Microphone Inputs 麦克风输入
Maximum Level 最高限制级别 +10 dBu (balanced, min gain)
Gain Range 增益范围 50 dB
Frequency Response 最高限制级别 20Hz - 20kHz (+/- 0.1dB, min gain, 48kHz)
Dynamic Range 动态范围 106 dB (A-wtd, min gain)
THD+N 失真度 + 噪音 0.005% (1kHz, -1 dBFS, unity gain)
EIN -128 dBu (max gain, 150Ω, A-wtd)
InputImpedance 输入阻抗 1.4K Ω
PhantomPower Phantom 电源 +48 VDC (10mA total)
Line/Instrument Inputs
MaximumLevel 最高限制级别 +10 dBu (balanced, min gain)
Gain Range 增益范围 50 dB
Frequency Response 频率响应 20Hz - 20kHz (+/- 0.1dB, min gain, 48kHz)
Dynamic Range 动态范围 106 dB (A-wtd, min gain)
THD+N 失真度 + 噪音 0.005%(1kHz, -1 dBFS, min gain)
InputImpedance 输入阻抗 750K Ω
Main Outputs
主输出
MaximumLevel 最高限制级别 +10 dBu (balanced)
Frequency Response 最高限制级别 20Hz - 20kHz (+/- 0.1dB, unity gain, 48kHz)
Dynamic Range 动态范围 106 dB (A-wtd)
THD+N 失真度 + 噪音 0.003%(1kHz, -1 dBFS)
Headphone Outputs
耳机输出
MaximumPower 最大功率 40 mW/channel (56Ω load)
Frequency Response 频率响应 20Hz -20kHz (+/- 0.2dB,56Ω load,48kHz)
Dynamic Range 动态范围 83 dB (A-wtd, 56Ω load)
THD+N 失真度 + 噪音 0.005%(1kHz, -1 dBFS, no load)
Impedance Working Range 阻抗工作范围 32Ω to 300Ω
