Pressure Systems, Inc. NetScanner™ System (9016, 9021, & 9022) User’s Manual
www.PressureSystems.com
1 - 2
NOTE: The newest PSI Intelligent Pressure Scanner is the 9022. Its serial numbers
begin with 1000. The 9022 is similar in function to the 9021 (using external
sensors), however, the 9022 features circular (military style connectors),
splash-proof case and connectors, antialiasing filters, and a jumper
selectable precision 5 or 10 volt excitation voltage for use with third-party
sensors. The overall dimensions of the 9022 are slightly larger than the
9021 due to a thicker top plate.
Model 9016
Model 9021
Model 9022
Figure 1.1
NetScanner
™
System Models 9016, 9021, and 9022 Intelligent Pressure Scanners
