Prestige APSRS - Wire Harness Colors and Functions

APSRS
Keyless Remote Start
Quick Installation Guide
For Complete Installation Guide and Technical
Support Visit
www.voxxuniversity.com
Or Call
1-800-225-6074
Notications Feature Programming
Remote Programming
1 Chirp 2 Chirp
3 Chirp 4 Chirp 5 Chirp
6 Chirp
1 Lock / Unlock Function 500ms 3.5sec
500ms L, DBL UL DBL L, 500ms UL DBL L, DBL UL 500ms L, 350ms UL
2 Ignition Lock OFF ON
3 Ignition Unlock OFF Unlock All
Unlock Driver
4 Exterior Illumination OFF With Arm
With Disarm With Arm & Disarm
5 Auto Relock OFF ON
6 Auto Arming / Locking NA
7 Notification Sound NA
8 Horn Timing 16ms 30ms
40ms 50ms 10ms
9 Valet Override Method NA
10 Driver Priority Unlock OFF ON
11 Silent Choice OFF From Transmitter
OEM Style
12 Security Profile OFF OEM Security
13 Door Trigger Input Negative Positive
14 Park Light / Trunk Swap OFF ON
15 Data Port Protocol ADS DBI
1 Chirp 2 Chirp
3 Chirp 4 chirp 5 Chirp 6 Chirp
1 Defrost Output Pulsed 10min
RS Runtime
2 RS Start Notification ON Off
3 RS Runtime 5min 10min
15min 20min 45min 60min
4 RS Parking Lights Steady Flashing
5 Engine Confirmation Tach Voltage
Data Hybrid
6 Voltage Level >0.5v B4 Start <0.5v B4 Start
7 Ignition 2 Output Ignition Accessory
Start
8 Ignition 3 Output Ignition Accessory
Start
9 Accessory Output Accessory Ignition
Start
10
Transmission Auto Manual
11 Max Crank Time 0.8sec 1.0sec
1.5sec 2.0sec 3.0sec 4.0sec
12 Diesel Delay OFF Diesel 10
Diesel 15 Diesel 20 Diesel 30
13 Temperature Start OFF ON
14 Crank Duration Averaging Preset
15 RS Shock Override NA
16 Turbo Timer OFF 3min
5min 10min
17 Start Activation Two Press One Press
Three Press
18 RS Lock Function No Change UL Before L After
UL Before Start Lock After Start
19 Factory Disarm Output Single Pulse Double Pulse
350ms 500ms 800ms Same As Bank 2, F1
20 Additional Unlock Pulse No Pulse IGN, ACC, GWR
IGN,ACC,GWR,PASD
Features
Feature Bank 2
Options
Features
Feature Bank 3
Options
1 Second Pulse
10 Second Pulse
15 Second Pulse
20 Second Pulse
30 Second Pulse
Push & Hold
Latch ON/OFF
Latch 10min
Latch Runtime
5 Second Pulse
Ch. 4 AUX
Lock
Unlock
2nd Unlock
Trunk
Remote Start Status
Ignition
Pulse After Shutdown
Domelight
Headlight
Defrost
LED
Ch. 5 AUX
Ch. 6 AUX
Ch. 7 AUX
Pulse During Crank
Accessory
Factory Arm
Factory Disarm
2018 Voxx Electronics. All Rights Reserved.
Tach Programming
1 Runtime Expired
2 Remote Shutdown
3 Brake On
4 Manual Mode
5 Hood Open
6 Low / No Tach
7 Tach Programming
8 High Tach
Negative Output Control (NOC) AUX Output Control
OEM Security
Negative output control allows any NOC to be programmed for any one of nineteen
(19) options. This feature is accessible via FlashLogic Weblink or Weblink Mobile.
Any AUX output can congured using the AUX Control Menu. This feature is only
accessible via FlashLogic Weblink or Weblink Mobile.
Chirp Delete
System ARM/DISARM chirps can be toggled ON or OFF without entering the
Feature Bank programming.
1. Turn the ignition key ON/OFF.
2. Press and release the valet button 3x.
The system will respond with one (1) chirp for ON and two (2) Chirps for OFF.
This feature will not affect alarm trigger or programming.
User Programmable LED
System LED notications can be turned ON or OFF without entering Feature
Bank programming.
1. Turn the ignition key ON/OFF, ON/OFF.
2. Press and hold valet button for ve (5) seconds.
The LED will ash 1x for ON, 2x for OFF. This feature will not affect LED ash
during programming.
Remote Start
If the remote start fails to start the vehicle, the system will ash the vehicle
parking lights to indicate the cause.
The installer must manually congure the Engine Conrmation method in Feature
Bank 3, Feature 5. The default method is “Tach”. This method requires using the
Green/Orange tach input wire. When using the default “Tach” method, the vehicle
tach rate must be programmed. To enter tach rate programming:
1. Turn the ignition key ON.
2. Press and release the valet button 3x.
3. Turn the ignition key OFF.
4. Press and hold valet button.
5. While holding valet button, start the engine using the key.
6. Hold the valet button for approximately ten (10) seconds. If connected to the
vehicle Tach source, the system will ash the parking lights 1x every second.
7. Release the valet button. The system will turn on the parking lights for two (2)
seconds to indicate the tach rate is programmed.
The APSRS Feature Banks can be programmed by using the valet button and
remote. To enter Feature Bank programming:
1. Turn the ignition key to ON.
2. Press and release the valet button 3x. System will beep and ash lights 1x for
Feature Bank 1, Remote Programming.
3. Cycle ignition key OFF/ON. System will beep and ash lights 2x for Feature
Bank 2.
4. Press valet button to cycle features. LED will ash to display feature number.
5. Press lock button to cycle options. System will beep to indicate option number.
6. Cycle ignition key OFF/ON. System will beep and ash lights 3x for Feature
Bank 3.
7. Press valet button to cycle features. LED will ash to display feature number.
8. Press lock to cycle options. System will beep to indicate option Number.
To exit Programming cycle ignition key OFF and wait ten (10) seconds. The System
will also automatically exit programming after sixty (60) seconds of no activity.
Important Update
The default Data Port Protocol of this system is ADS. If using an
FLCAN or other external integration module be sure to choose
iDatalink 2-Way when ashing.
This system will also support DBI. This will require programming
Feature Bank 2, Feature 15 to DBI.
The APSRS can provide OEM level security. The system will monitor all entry zones
(Door, Hood, And Trunk). When an entry zone is detected the system will beep the
vehicle horn and ash the parking lights. This feature must be activated in Feature
Bank 2, Feature 12.
Operation
To arm the system, press lock function on the remote.
To disarm the system, press the unlock function on the remote.
Valet Override Procedure
To disarm the system without the use of a remote, turn the ignition key to ON and
press the valet button 1x.
The APSRS does not include an RF remote kit. The RF remote kit Includes two
(2) remotes, one (1) antenna, and one (1) cable. When added, remotes must be
programmed to the system. Remote Programming is located in Feature Bank 1. To
enter Remote Auto Programming:
1. Turn the ignition key to ON.
2. Press and release the valet button 3x. System will beep and ash the parking
lights 1x.
Press the lock button on each remote. The system will beep 1x to indicate the
remote has been programmed. If programming one (1) button remotes, press the
Start button. Only primary remote functions are auto programmed. This Includes
Lock, Unlock, and Trunk/Start.
If using AUX output control, you must manually program the AUX output channels
to the remote. Please see the complete installation guide for manual remote
programming instruction.
Note: If programming 2-Way remotes, wait for the remote to beep before
programming additional remotes. This beep is conrmation that a 2-Way response
has been received from the main module.
The Feature Banks below can also be programmed using the FlashLogic Weblink or Weblink Mobile.
Please visit www.FlashLogic.com for more detail.
