Prestige Excellence - Page 83

76
8
3
4
1
6
5
2
7
Fig. 36: PRESTIGE Excellence Control Enclosure
Replacement Parts
Item Part # Description
1 PTRKIT109 Pressure Gauge and Fitting
2 PTSWI01 Power Switch
3 PTSWI02 Power Switch Cover
4 PTRKIT108 Control Enclosure
5 PTRKIT205 TriMax Control Module
6 PTRKIT207 TriMax Display Module
7 PTCON19 Control Enclosure Cover
8 PTGRO01 Igniter Cable Grommet
9 PTFUSE02 TriMax Control Module 5A Fuse (Not Shown)
10 PTFUSE01 Circulator 2.5A Fuses (Not Shown)
11 PTFUSE03 In-Line Voltage 8A Fuse (Not Shown)
