Prestige Excellence - Page 98

Installation - Domestic Piping
8
DHW Aux.
Connection
DHW
Cold Water
Inlet
Air Vent
Connection
DHW
Hot Water
Outlet
T&P Valve
(Drain Piping Not Shown)
Fig. 2: Standard Installation of the T&P Relief Valve
Drain
Dip Tube
3/4” Brass Close
Nipple
DHW Aux.
Connection
DHW
Hot Water
Outlet
DHW
Cold Water
Inlet
Air Vent
Connection
3/4” Brass
Tee
T&P Valve
(Drain Piping Not Shown)
Fig. 3: Commonwealth of Massachusetts Installation
