ELECTRICAL CoNNECTIoN
Type 3
230V
P
t
Br
B
Y/Gr
X11.
4 5 1 2
1
2 345
Br
B
Bk
R
Bk
W
Br
B VV
WW
B B
Or Or
V B
RR Bk
Br
B
R
Bk
Br
RRB
G
G
R
Br Br
Or
V
Br
R
Bk
Br 11
10
9 8 7 6 5 4 3
13 12
2 1
Or
Bk B
Br
B
X12.1 X12.2 X12.3
B
B
R
B
B
B
B
G
G
X1.1
X10
X7
X1.2 X1.6 X1.4 X1.5 X1.3 X2.1 X2.2 X2.3 X2.4
X2.11 X2.12
X2.6 X2.8
X2.10
X2.9 X3.1 X3.2 X3.3 X3.5 X3.4 X4.1 X4.3 X4.2 X2.5 X5.1 X5.2
WIRING DIAGRAM : PRESTIGE 24-32 / Solo – Excellence
1. 230V connection cord
2. Start/Stop switch
3. Water tank charging pump socket
4. Heating pump
5. Burner
6. Gas valve
7. 230Volt - 24Volt transformer
8. MCBA
9. Screen
10. Water pressure switch
11. NTC1 flow sensor
12. NTC2 return sensor
13. NTC3 domestic hot
14. NTC5 flue gas temperature
15. Room thermostat (optional)
16. NTC4 outdoor temperature
17. NTC6 sensor for the circuit (optional)
18. Shell B (optional)
19. Shell A (optional)
20. Zero volt of 24V circuit.
21. Connection pumps (if two circuit)
B. Blue Bk. Black Br. Brown G. Grey Or. Orange R. Red V. Violet W. White Y/Gr. Yellow/Green
1
2
3
5
4
21
7
8
6
9
14
12
11
10
15 13 16 17
20 18 19
