4601— 10/17USL.7 Made in China for Prevue Pet Products, Inc., 224 N Maplewood Ave, Chicago IL 60612 USA • www.prevuepet.com • 1 [800] 243-3624 • customerservice @ prevuepet.com
2
...continued
SUPPORTBAR
Insert the support bar
into the holders. This
will provide support for
the floor tray.
Cutaway view
ROOMDIVIDER
HUTCHFLOOR
TRAY
Slide the room divider panel
down into place.
Insert the floor tray.
When the floor tray is in place, the
trap door can be closed to separate
the upper and lower levels.
