F030— 02/17—USL.3 For more wonderful cages, toys, and accessories for dogs, cats, birds, chickens, rabbits, ferrets and small animals, visit www.prevuepet.com
4
5
To install the ROOF, you will
need these pieces:
To install the COMPONENTS
,
you will need these pieces:
Food/water cups:
H
ook the cups onto the horizontal wire
under the doors on the side panels.
Grille and tray:
Slide the grille into the top channel and
the tray into the bottom channel.
× 4
× 4 ( long screws )
Lay the V-shaped roof beam, centered, across
the peak. Lay the roof mesh, centered, on top.
Hook the roof onto the loops along the top edge
of the front and back panels. (See fig.5.2)
Secure the roof with short screw + washer
pairs in eight places along the roof frame.
fig.5.3
fig.5.2
fig.5.1
× 8 pair
