6.1 HIGH VOLTAGE PWR SUPPLY #1:
Ref. # Description MFR. Part No.
ASSY DX-300 HIGH VOLTAGE PWR SUPPLY #1 01-0300-01
PCB DX-300 HIGH VOLTAGE PWR SUPPLY 82-0300-01
Resistors
Ref. # Description MFR. Part No.
R13
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R14
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R15
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R16
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R17
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R18
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R19
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R20
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R21
Resistor, Carbon Film 150K Ohm 2W 10% 06-1504-02
R22
Resistor, Carbon Film 150K Ohm 2W 10% 06-1504-02
R23
Resistor, Carbon Film 150K Ohm 2W 10% 06-1504-02
R24
Resistor, Carbon Film 6.8 Ohm 2W 5% 06-0680-02
R25
Resistor, Carbon Film 6.8 Ohm 2W 5% 06-0680-02
R26
Resistor, Wire wound 25 Ohm 10W 10% 17-2500-10
Capacitors
Ref. # Description MFR. Part No.
C14
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C15
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C16
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C17
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C18
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C19
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C20
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C21
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C22
Capacitor, Electrolytic 100µF 450V 23-0107-45
C23
Capacitor, Electrolytic 100µF 450V 23-0107-45
C24
Capacitor, Electrolytic 100µF 450V 23-0107-45
Diodes
Ref. # Description MFR. Part No.
D9
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D10
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D11
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D12
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D13
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D14
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D15
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D16
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
