Pride DX300 CHAPTER 6
CHASSIS (Cont.)
Ref. # Description MFR. Part No.
L7
ASSY. Tank Coil 15-80 Meters 01-0300-15
L12
Choke, RF 1mH 160 MA 24-1006-00
Capacitor Strap 85-0300-17
Ref. # Description MFR. Part No.
Dial, Figure Black DX-300 32-0299-00
Knob, Black DX-300 32-2912-00
Knob, Black DX-300 32-2912-01
CAP. Knob DX-300 42-0290-00
LED1
L.E.D. Red Diffused 49-5024-00
LED2
L.E.D. Red Diffused 49-5024-00
LED3
L.E.D. Red Diffused 49-5024-00
LED4
L.E.D. Red Diffused 49-5024-00
Clip & Ring, LED Panel Mounting 05-5024-00
Z1
Parasitic Suppressor, Grid 4Turns #22 01-0300-07
Resistor, Carbon Film 150 Ohm 1/2W (R65)
Z2
ASSY. Parasitic Suppressor 01-0300-05
Resistor, Carbon Film 100 Ohm 2W (R62)
Resistor, Carbon Film 100 Ohm 2W (R63)
Resistor, Carbon Film 100 Ohm 2W (R64)
L9
Choke, RF Plate 55µH 24-0014-00
T1
Transformer, DX-300 High Voltage 25-0300-01
T2
Transformer, DX-300 Low Voltage 25-0300-02
BL1
Blower, High Output Modified 87-1250-00
Flange, Outlet For Blower PN 87-1250-00 87-1250-01
Ref. # Description MFR. Part No.
V1
Tube, 4CX250B 65-0250-00
Socket, Electron Tube E.F. Johnson 124-110 09-0250-00
Screen bypass Cap, Round Frame E.F. Johnson 124-113-001
Socket Chimney, E.F. Johnson 124-0111-011 09-0250-01
Ref. # Description MFR. Part No.
PL-1
Line Cord. 3 Wire 1118W Molded Plug 28-3186-00
PL-2
SO239 (RF Input)
PL-3
SO239 (RF Output)
PL-4
Recept 3-COND Round (Metering Jack) 09-7135-00
RV1
POT. 500 Ohm 2.25W 10% SCR. ADJ. .625 SHFT 18-5001-02
F1
Fuse, AGC 10 AMP 65-0010-00
Fuse Extractor Post 67-1200-00
Ref. # Description MFR. Part No.
Foot, Rubber 31/32" 75-2135-00
Cover 85-0300-11
Bottom Plate 85-0300-14
