Pride DX300 CHAPTER 6
6.5 RF INPUT AND CONTROL BOARD:
Ref. # Description MFR. Part No.
ASSY. RF INPUT AND CONTROL 01-0300-03
RF INPUT AND CONTROL PCB 82-0300-03
Inductors
Ref. # Description MFR. Part No.
L1
Choke, SUB MIN 200µH NIN Q47 80 METERS 24-2000-00
L2
ASSY. Coil Input Toroid 40 METERS 01-0300-26
L3
ASSY. Coil Input Toroid 20 METERS 01-0300-25
L4
ASSY. Coil Input Toroid 15 METERS 01-0200-24
L5
ASSY. Coil Input Toroid 10 METERS 01-0300-23
L10
Choke, RF 22 µH 24-2200-00
L11
Choke, RF 0.82 µH 24-0820-00
L14
Choke, SUB MIN 200µH NIN Q47 24-2000-00
T3
ASSY. Input Transformer 3 Wires 10 Windings 01-0300-22
Resistors
Ref. # Description MFR. Part No.
R44
Resistor, Carbon 1.5K Ohm 2W 10% 06-1502-02
R45
Resistor, Carbon 1.5K Ohm 2W 10% 06-1502-02
R46
Resistor, Carbon 18K Ohm 2W 10% 06-1803-02
R47
Resistor, Carbon 18K Ohm 2W 10% 06-1803-02
R48
Resistor, Carbon 270 Ohm 2W 10% 06-2701-02
R49
Resistor, Carbon 270 Ohm 2W 10% 06-2701-02
R50
Resistor, Carbon Film 1K Ohm 1W 06-1002-01
R51
Resistor, Carbon Film 470 Ohm 1/2W 5% 06-4701-00
R52
Resistor, Carbon Film 680 Ohm 1/2W 5% 06-6801-00
R53
Resistor, Carbon Film 680 Ohm 1/2W 5% 06-6801-00
R54
Resistor, Carbon Film, 10K Ohm 1/2W 5% 06-1003-00
R55
Resistor, Carbon Film 270 Ohm 1/2W 5% 06-2701-00
R56
Resistor, Carbon Film 470 Ohm 1/2W 5% 06-4701-00
R57
Resistor, Carbon Film 68K Ohm 1/2W 5% 06-6803-00
R58
Resistor, Carbon Film 1K Ohm 1/2W 5% 06-1002-00
Capacitors
Ref. # Description MFR. Part No.
C39
Capacitor, Ceramic Disk 0.01µF 1KV 08-0103-02
C40
Capacitor, Ceramic Disk 0.01µF 1KV 08-0103-02
C41
Capacitor, Dipped Mica 39pF 5% DM15 21-1390-00
C42
Capacitor, Dipped Mica 10pF 5% DM15 21-1100-00
C43
Capacitor, Ceramic Disk 0.01 µF 1KV 08-0103-02
C50
Capacitor, Ceramic Disk 0.01µF 50V 05-0103-00
C51
Capacitor, Electrolytic 35µF 25V Axial 22-0356-00
C52
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C53
Capacitor, Dipped Mica 120pF 5% DM15 21-1121-00
C54
Capacitor, Dipped Mica 50pF 5% DM15 21-1500-00
C55
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
Diodes
Ref. # Description MFR. Part No.
D29
Diode, Signal 1N914 48-0914-00
D30
Diode, Rectifier 1A 50V Plastic 48-4001-00
D31
Diode, Rectifier 1A 50V Plastic 48-4001-00
D32
Diode, Signal 1N914 48-0914-00
Relays
Ref. # Description MFR. Part No.
RL1
Relay, 4PDT Allied Control TY154-4C-12DC 41-1024-00
RL2
Relay, 2PDT Potter & Brumfield R10-E1-Y2-V185 41-1022-01
Transistors
Ref. # Description MFR. Part No.
Q1
Transistor, 2N2905 PNP SI Switching 48-2905-00
Q2
Transistor, 2N2905 PNP SI Switching 48-2905-00
