Pride DX300 CHAPTER 6
6.4 LOW VOLTAGE PWR SUPPLY:
Ref. # Description MFR. Part No.
ASSY. LOW VOLTAGE PWR SUPPLY 01-0300-02
LOW VOLTAGE PWR SUPPLY PCB 82-0300-02
Resistors
Ref. # Description MFR. Part No.
R27
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R28
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R29
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R30
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R31
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R32
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R33
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R34
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R35
Resistor, Carbon Film 150 Ohm 1/2W 10% 06-1501-00
R36
Resistor, Carbon 30 Ohm 1/2W 5% 06-0301-00
R37
Resistor, Wire wound 20K Ohm 10W 17-2003-10
R38
Resistor, Wire wound 12K Ohm 10W 10% 17-1203-10
R39
Resistor, Wire wound 10K Ohm 10W 10% 17-1003-10
R40
Resistor, Carbon 3.3K Ohm 2W 5% 06-3302-02
R41
Resistor, Carbon 3.3K Ohm 2W 5% 06-3302-02
R42
Resistor, Carbon Film 680 Ohm 1/2W 5% 06-6801-00
Capacitors
Ref. # Description MFR. Part No.
C25
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C26
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C27
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C28
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C29
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C30
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C31
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C32
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C33
Capacitor, Electrolytic 40µF 450V 23-0406-45
C34
Capacitor, Electrolytic 40µF 450V 23-0406-45
C36
Capacitor, Electrolytic 1000µF 25V 22-0108-00
C37
Capacitor, Electrolytic 1000µF 25V 22-0108-00
Diodes
Ref. # Description MFR. Part No.
D17
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D18
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D19
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D20
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D21
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D22
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D23
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D24
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D25
Diode, Zener 82V 5W 1N5375 48-5375-00
D26
Diode, Rectifier 1N4001 1A 600PIV 48-4001-00
D27
Diode, Rectifier 1N4001 1A 600PIV 48-4001-00
D28
Diode, Rectifier 1N4001 1A 600PIV 48-4001-00
