Pride DX300 CHAPTER 6
6.6 WATTMETER PCB:
Ref. # Description MFR. Part No.
ASSY. WATTMETER PCB 01-0300-09
WATTMETER PCB 82-0300-06
Inductors
Ref. # Description MFR. Part No.
T4
ASSY. Toroid Coil 17 Winding 01-0300-27
Resistors
Ref. # Description MFR. Part No.
RV2
Potentiometer, Trimpot 50K Ohm 1/4 W 19-5003-00
R60
Resistor, Carbon Film 15K Ohm 1/2W 5% 06-1503-00
R61
Resistor, Carbon Film 68 Ohm 2W 5% 06-6800-02
Capacitors
Ref. # Description MFR. Part No.
C57
4-60pF
C58
Capacitor, Dipped Mica 330pF 5% DM-15 21-1331-00
C59
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C60
Capacitor, Ceramic 0.1µF 100V 08-0104-02
Diodes
Ref. # Description MFR. Part No.
D33
Diode, Signal 1N914 48-0914-00
Meters
Ref. # Description MFR. Part No.
M1
Meter, 1ma F.S. With Special Scale 49-0300-00
6.7 CHASSIS
Ref. # Description MFR. Part No.
C1
Capacitor, Ceramic Disk 0.01µF 1KV 08-0103-02
C2
Capacitor, Ceramic Disk 0.01µF 1KV 08-0103-02
C35
Capacitor, Ceramic Disk 0.001µF 1KV (Across LED4) 08-0102-00
C44
Capacitor, Ceramic Disk 0.01µF 1KV 08-0103-02
C45
Capacitor, Ceramic Disk 0.01µF 1KV 08-0103-02
C46
Capacitor, Ceramic Disk 0.01µF 1KV 08-0103-02
C47
Capacitor, Ceramic Disk 0.01µF 1KV 08-0103-02
C48
Capacitor, Ceramic Disk 0.01µF 1KV 08-0103-02
C49
Capacitor, Ceramic Disk 0.01µF 1KV 08-0103-02
C62
Capacitor, Ceramic Disk 0.01µF 1KV 08-0103-02
C63
Capacitor, Dipped Mica 360pF 1KV 21-1361-01
C64
Capacitor, Dipped Mica 360pF 1KV 21-1361-01
C65
ASSY. CAPACITOR 165pF TEFLON DIELECTRIC 01-0300-13
Teflon Sheet 4.50 X 3.50 85-0300-04
Teflon Plug 1.0 DIA 85-0300-05
Brass Sheet 4.00 X 3.00 85-0300-06
Teflon Sheet 2.00 X 2.00 85-0300-07
Brass Sheet 1.40 X 1.40 85-0300-08
C66
Capacitor, Variable, Panel 10-110pF 3KV 20-1101-03
C67
Capacitor, Variable, Panel 1350pF 750V (450pF x 3) 20-2450-00
C68
Capacitor, Ceramic Disk 0.0022µF 7.5KV 08-0222-07
C69
Capacitor, Ceramic Disk 0.001µF 1KV (Across LED3) 08-0102-00
C70
Capacitor, Ceramic Disk 0.01µF 1KV 08-0103-02
Ref. # Description MFR. Part No.
S1
Switch, SPST, l0A 40-8006-00
S2
Switch, 3A SPST 40-1606-00
S3
Switch, 3A SPST 40-1606-00
S4
Switch, DPDT, Center Off 10A 40-8706-00
S5
Switch, Band Ceramic 2 Wafer 5 Position 40-9002-00
Coupler, Shaft 26-0138-00
S6
Switch, Phonetic 1 Pole 5 Position 40-3000-00
