Pride DX-300 - High Voltage Power Supply PCB #2; Safety Interlock PCB

32
Copyright © 2004 CBTricks.com
Pride DX300 CHAPTER 6
6.2 HIGH VOLTAGE PWR SUPPLY #2:
Ref. # Description MFR. Part No.
ASSY.HIGH VOLTAGE PWR SUPPLY #2 01-0300-00
HIGH VOLTAGE PWR SUPPLY PCB 82-0300-01
Resistors
Ref. # Description MFR. Part No.
R1
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R2
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R3
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R4
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R5
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R6
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R7
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R8
Resistor, Carbon Film 470K Ohm 1/2W 06-4704-00
R9
Resistor, Carbon Film 150K Ohm 2W 10% 06-1504-02
R10
Resistor, Carbon Film 150K Ohm 2W 10% 06-1504-02
R11
Resistor, Carbon Film 150K Ohm 2W 10% 06-1504-02
R12
Resistor, Wire wound 25 Ohm 10W 10% 17-2500-10
Capacitors
Ref. # Description MFR. Part No.
C3
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C4
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C5
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C6
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C7
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C8
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C9
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C10
Capacitor, Ceramic Disk 0.001µF 1KV 08-0102-00
C11
Capacitor, Electrolytic 100µF 450V 23-0107-45
C12
Capacitor, Electrolytic 100µF 450V 23-0107-45
C13
Capacitor, Electrolytic 100µF 450V 23-0107-45
Diodes
Ref. # Description MFR. Part No.
D1
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D2
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D3
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D4
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D5
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D6
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D7
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
D8
Diode, Rectifier 1N4007 1 AMP 1000PIV 48-4007-00
6.3 B+ CIRCUITRY (Safety Interlock):
Ref. # Description MFR. Part No.
ASSY. B+ CIRCUITRY (Safety Interlock) 01-0300-16
PCB, B+ CIRCUITRY 82-0300-04
Inductors
Ref. # Description MFR. Part No.
L8
ASSY. Toriod Inductor 10µH 10 Windings 01-0300-28
Resistors
Ref. # Description MFR. Part No.
R59
Resistor, Carbon Film 150K Ohm 2W 10% 06-1504-02
Capacitors
Ref. # Description MFR. Part No.
C56
Capacitor, Ceramic Disk 0.005µF 3KV 08-0502-00
Ref. # Description MFR. Part No.
Ground Strap, Safety Interlock 85-0300-15
Bracket, B+ Circuitry 85-0300-18
