Section 5: Specifications
24
FMX500 FMX600
Working Width 60” 72”
Overall Width 61” 73”
Overall Length (Including Gauge Wheels)
58” 62”
Weight (with Front Guard) 504 lbs 542 lbs
Floating Top Link Permits deck to float over terrain for a professional finish.
High Blade Speed Tip
FPM (Feet Per Minute)
Ensures a clean cut.
17,288 FPM 17,319 FPM
Blades
(1/2” Bolt and Nut)
3 —1/4” x 2.5 x 20-1/2” 3 —1/4” x 2.5 x 24-1/2”
*All blades measurements are from tip to tip.
Deck Height
(bottom of deck to bottom of skid)
5”
Deck Material Thickness Fully welded deck for additional strength. 10 Gauge
5/8” Belts B-73 are 76” Long B-78 are 81” Long
Minimum Horsepower Rating
Minimum Maximum
20 HP 45 HP
Minimum Maximum
25 HP 60 HP
Gearbox 540 RPM PTO Driven Gearbox 1:1:93 Cast Iron Housing
Gearbox Oil SAE 85W-140 EP
Oil Capacity 23 Oz (.68 liters)
Cutting Height 1 1/4 to 4” Provides perfect cutting height for a professional finished landscape
Cutting Capacity Grass and weeds
Safety Guards Protects against flying object hazards. Rubber belting rear discharge.
Gauge Wheel
Allows the operator to raise or lower the wheels by adjusting the gauges in increments of
1/2” to 1”.
Gauge Wheel 10” Solid Rubber 10” Solid Rubber
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE!
Driveline Safety Protection 1/4" square shear key. Series 4 PTO Driveline 32" Cross to Cross
FMX MODEL SPECIFICATIONS
