RMH 700 RMH 700D
Working Width 84” 84”
Overall Width 92” 92”
Overall Length (Including Tail-Wheel)
128” 129"
Weight (with Front Guard) 1565 lbs 1605 lbs
High Blade Speed Tip
FPM (Feet Per Minute)
14,369 FPM
Blades 1/2”x4” Heat Treated Alloy Steel - Free swing blades
1-1/2” Bolt and Nut
Deck Height
(bottom of deck to bottom of skid)
8 1/2” 8 1/2”
Deck Material Thickness 3/16” 3/16”
Deck Design Fully welded for additional strength.
Shaped to discharge grass more effectively than other models.
Minimum Horsepower Rating Minimum Maximum
60 HP 120 HP
Gearbox Vertical mount 90
o
with 1-3/8” Spline Input and tapered spline output with hub.
540 rpm PTO Driven Gearbox 1:1:21Cast Iron Housing
Gearbox Oil SAE 85W-140EP
Oil Capacity 62 Oz (1.8 Liters)
Cutting Height 1-3/4” to 12” 1-3/4” to 12”
Cutting Capacity Commercial—Heavy Brush and grass, cuts up to 3” in thickness. Commercial—Heavy Brush and grass, cuts up to 3” in thickness.
Safety Guards Protects against flying object hazards. Chain Guard (Front and Back)
Skids Replaceable side wear skid plates.
Provides sidewall reinforcement and full protection to bottom sidewall with a bolt on
Abrasion Resisting “AR” Wear Form 400 Skid.
Stump Jumper Allows mower to slide over obstructions while protecting the gearbox output shaft.
Oval Pan 1/4” thickness.
Driveline Shielded Series 6 PTO Shaft 40” with 4 – Disk Slip Clutch Shielded Series 6 PTO Shaft 40” with 4 – Disk Slip Clutch
Tail-Wheel 4” x 8” x 15” Laminated Tire, Cast Iron Hub. 2 — 4” x 8” x 15” Laminated Tire, Cast Iron Hub.
Heavy Duty Spindle on Tail-Wheel 2” Spindle gives the strength to protect tail-wheel assembly. 2” Spindle for each wheel gives the strength to protect
tail-wheel assemblies.
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE!
Ensures a clean cut
Section 5: Specifications
27
RMH MODEL SPECIFICATIONS
