25
Section 5: Specifications
RMS 400 RMS 500 RMS 600
Working Width 48” 60” 72”
Overall Width 54” 67” 79”
Overall Length (Including Tail-Wheel)
82” 98” 108”
Weight (with Front Guard) 490 lbs 545 lbs 738 lbs
High Blade Speed Tip
FPM (Feet Per Minute)
Ensures a clean cut.
13,096 FPM 12,469 FPM 14,963 FPM
Blades Heat Treated Alloy Steel
- Free Swing Blades
1-1/2” Bolt and Nut
3/8” x 3” x 16” 1/2” x 3-1/2” x 22” 1/2” x 4” x 28”
*All Blades Measurements are from hole center line to blade tip.
Deck Height
(underside of deck to bottom of skid)
8 3/8”
Deck Material Thickness 12 Gauge
Deck Design Fully welded for additional strength.
Shaped to discharge grass more effectively than other models.
Minimum Horsepower Rating
Minimum Maximum
20HP 45HP
Minimum Maximum
25HP 60HP
Minimum Maximum
25HP 60HP
Gearbox Vertical mount 90
o
with Smooth Input
with 1/2” shear bolt (Grade 2); tapered
spline output with hub. 540 rpm PTO
Driven Gearbox ratio: 1:1:93 Cast
Iron Housing
Vertical mount 90
o
with Smooth Input
with 1/2” shear bolt (Grade 2); tapered
spline output with hub. 540 rpm PTO
Driven Gearbox ratio: 1:1:47 Cast
Iron Housing
Vertical mount 90
o
with Smooth Input with
1/2” shear bolt (Grade 2); tapered spline
output with hub. 540 rpm PTO Driven
Gearbox ratio: 1:1:47 Cast Iron Housing
Gearbox Oil SAE 85W-140EP
Oil Capacity 23 Oz (.68 Liters)
SAE 85W-140EP
Oil Capacity 23 Oz (.68 Liters)
SAE 85W-140EP
Oil Capacity 23 Oz (.68 Liters)
Cutting Height 1-3/4” - 12”
Cutting Capacity Grass, weeds and light brush not exceeding 1" dia.
Safety Guards Protects against flying object hazards. Rubber (Front and Rear) or Optional Chain Guard (Front and Rear).
Skids Provides sidewall reinforcement and full protection to bottom sidewall.
1/4” x 2” weld on.
Stump Jumper Allows mower to slide over obstructions while protecting the gearbox output shaft.
Oval Pan 1/4” thickness
Driveline Safety Protection Shielded Series 4 PTO Shaft 28” with
1/2” Shear Pin Grade 2 with Snap
Ring (uses #2 Grade Bolt)
Tail-Wheel 4” x 8” x 15” Laminated Tire
Heavy Duty Spindle on Tail-Wheel 1-1/2” Spindle gives the strength to protect tail-wheel assembly.
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE!
Shielded Series 4 PTO Shaft 32” with
1/2” Shear Pin Grade 2 with Snap
Ring (uses #2 Grade Bolt).
Shielded Series 4 PTO Shaft 36” with
1/2” Shear Pin Grade 2 with Snap
Ring (uses #2 Grade Bolt).
RMS MODEL SPECIFICATIONS
