Primare CD21 - Using the CD21 with Other Primare Products; Technical Specification

2
CD21 COMPACT DISC PLAYER USER GUIDE
Technical speci cation
Mechanism
DVS "Ultra Silent"
D/A Converter
2 x Burr-Brown PCM 1738
Output Analogue
2.0 VRMS
Output Impedance
100
Ω
Frequency Response
20Hz – 20kHz (+0/0.2dB)
Signal to Noise Ratio
105dBA
Harmonic Distortion
<0.01% (20Hz – 20kHz)
Digital Output
75
Ω
coaxial (SPDIF)
110
Ω
AES/EBU
TOSlink
Power Consumption
Standby <16W
Dimensions
430 x 385 x 100mm
Weight
10kg
INTRODUCTION
Intuitive user interface
In keeping with the philosophy of the Primare range
of systems, the CD21 can be controlled through a very
simple and intuitive interface, designed so that it will not
distract you from the pleasure of listening to music on
your system.
In fact most of the features of the CD21 can be accessed
through just six front panel push buttons. The full set of
functions, including scan and programming, is available
using the remote control supplied with the CD21.
Alternatively, all the functions of the CD21 can be con-
trolled by the optional C22 remote control, along with the
other Primare components in your system.
Using the CD21 with other Primare
products
Although the CD21 Compact Disc Player is  exible
enough to work with virtually any other equipment you
have in your system, it is ideally suited for use with the
Primare I21 Integrated Ampli er. A particular bene t of
using the CD21 with a Primare preampli er is that you
can control your entire system with a single remote
control, to give you a fully integrated system with the
simplest possible user interface.
