11 Display on the device
The display on the device shows the measured power in watts. The device types are
designed for different maximum permissible laser powers and have displays with differ-
ent resolutions (see Tab. 11.1 on page22).
A resolution of 0.1W or 0.01W means that the instrument measures in steps of 1/10W
or 1/100W. The measured values are displayed precisely to the first or second decimal
place. A resolution of 1W means that the instrument measures in steps of 1W. Decimal
places are not displayed.
Device type Maximum permissible
laser power
Resolution Measuring
steps
PMT01 100W 0.01W 1/100W
PMT05 500W 0.1W 1/10W
PMT30 3000W 1W 1W
PMT70 7000W 1W 1W
PMT120 12000W 1W 1W
Tab. 11.1: Display resolution depending on the device type
