16.2 Device typesicu/iag
Measurement parameters PMT 70iag, 70icu
1)
PMT 120iag, 120icu
1)
Laser power range 350 – 7000W
2)
500 – 12000W
2)
Wavelength range 800 – 1100 nm oder 10.6 μm
Max. beam diameter on the absorber
(inlet aperture)
36mm
Max. power density on the absorber
(inlet aperture)
5kW/cm² for 5kW
Irradiation time 10 s (at maximum permissible laser power),
20s (at 50% of the maximum permissible laser
power)
Device parameters
Max. angle of incidence perpendicular
to inlet aperture
±5°
Max. centered tolerance ±2.0mm
Measuring accuracy ±4%
Reproducibility ±2%
Dimensions and Weight
Absorber height 75mm
Absorber diameter 79mm 99mm
Weight (approx.) 1110g 1550g
