Primes PMT 01 - 16 Technical Data; Device Types P

35,0(6
PocketMonitorPMT
33
Revision 01/2020 EN
16 Technical data
16.1 Device typesp
Measurement parameters PMT01p
1)
PMT05p
1)
PMT30p
1)
Laser power range 5 – 100W
2)
25 – 500W
2
150 – 3000W
2
Wavelength range 800 – 1100 nm oder 10,6 μm
Max. beam diameter on the absorber
(inlet aperture)
15mm 27.5mm 48mm
Max. power density on
the absorber
(inlet aperture)
for <1kW 2.5kW/cm² 2.5kW/cm² 2.5kW/cm²
for <3kW — — 1.5kW/cm²
Irradiation time 10 s (at maximum permissible laser power),
20s (at 50% of the maximum permissible laser
power)
Device parameters
Max. angle of incidence perpendicular
to inlet aperture
±5°
Max. centered tolerance ±2.0mm
Measuring accuracy ±4%
Reproducibility ±2%
Dimensions and Weight
Absorber height 20mm 15mm 20mm
Absorber diameter 25mm 45mm 79mm
Weight (approx.) 530g 560g 670g
