Primes PMT 01 - Page 5

35,0(6
PocketMonitorPMT
5
Revision 01/2020 EN
10 Control Elements 21
11 Display on the device 22
12 Measuring with the PocketMonitorPMT 23
12.1 Safety instructions................................................................................ 23
12.2 Maximum permissible laser power ....................................................... 24
12.3 Measure via the operating unit ............................................................. 24
12.3.1 Get ready for measurement .................................................... 24
12.3.2 Perform measurement ............................................................ 25
12.4 Measure via the analog current loop interface
(only device types sep/out) ................................................................... 26
12.4.1 Get ready for measurement .................................................... 26
12.4.2 Perform measurement of the laser power ............................... 28
12.4.3 Perform measurement of the absorber temperature ............... 29
12.5 Cool the absorber in water for series measurements ............................ 30
12.6 Possible errors ..................................................................................... 30
13 Maintenance and service 31
14 Measures for the product disposal 31
15 Declaration of conformity 32
16 Technical data 33
16.1 Device typesp ..................................................................................... 33
16.2 Device typesicu/iag ............................................................................. 35
17 Dimensions 37
17.1 PMT 01p .............................................................................................. 37
17.2 PMT 01p sep, 01p sep/out .................................................................. 38
17.3 PMT 05p .............................................................................................. 39
17.4 PMT 05p sep, 05p sep/out .................................................................. 40
17.5 PMT 30p .............................................................................................. 41
