Specifications:
Model 1E49F (Engine Family 3ZHIS.0642CR)
Type Single-cylinder, two stroke, air-cooled
Cylinder bore 49mm
Piston stroke 34mm
Displacement 64.1 cc
Max. output ≧2.70 kw, (3.8 hp)
Speed at max. output 8500 rpm
Max. torque ≧3.5N.m
Idle speed ≦2400 rpm
Lock-up speed of clutch 3800 rpm
Min. fuel consumption ≦544 g/(kw.h)
Gasoline Minimum octane rating 93
Oil Two stroke engine oil
Engine
Fuel mix
Mix ratio 50:1
21
