Item Ref Description Qty Item Ref Description Qty
1 EHS400-02007A
Transmission
box
1 12
EHS400-03003-
01A
Support 1
2 1E49F01006 Cover 3 13
EHS400-03003-
02A
Wheels 2
3 1E49F07019 Screw M6×16 3 14 GB97.2-85 Washer 8 2
4 1E49F01010 Plug 3 15 1E49F07018 screw M5×25 2
5 1E49F01011 Screw M5×20 5 16 GB894.1-86 Spring lock 8 2
6 EHS400-02005A Clamping lever 1 17 1E49F07021
Screw M5 ×
24
2
7 EHS400-02006A Cover 1 18
EHS400-03001
A
Handle frame 1
8 1E49F07017 Screw M5×12 2 19 1E49F07017
Screw M5 ×
12
2
9 EHS400-02008 V-belt 1 20 EHS400-03002
Handle
bracket
1
10 EHS400-02001A Belt Tensioner 1 21 1E49F07019 Screw M6×16 1
11 EHS400-03003-03 Wheel shaft 2 22 EHS400-02009
Transmission
box cover
1
58
