Printware iJet Press - Appendix A - Printer Specifications

APPENDIX A
74
Appendix A – Printer Specifications
SPEED (color or mono)
Page Printing 8.5” x 11”
No. 10 Envelopes
Up to 3,600 per hour (1600 x 800 dpi @12 ips)
Up to 7,500 per hour (1600 x 800 dpi @ 12 ips)
MEDIA SIZE
Minimum: 3" W X 4.125" L (76.2 mm W x 104.76 mm L)
Maximum: 9.5" W x 17" L (241.3 mm W x 431.8 mm L)
MEDIA THICKNESS
Minimum: 0.004" (0.102 mm)
Maximum: 0.020" (0.5 mm / 430 gsm / 160# Cover / 240# Index)
PRINT QUALITY
Normal: 1600 x 800 DPI @ 12 ips
Best: 1600 x 1600 DPI @ 6 ips
TECHNOLOGY
Memjet
®
Thermal Inkjet
INK CAPACITY
Cyan (250 ml); Yellow (250 ml); Magenta (250 ml); Black (500 ml)
PRINT AREA
8.5" W x 17" L (215.9 mm W x 43.81 mm L)
COLOR MATRIX
Up to 16.8 million colors
FEEDER
Top Loading Friction Feeder Built-In.
PC INTERFACE
USB, Ethernet
FIRMWARE UPDATE
Electronic Download via PC connection
TRANSPORT
Pressure roller system with Star Rollers
FEATURES
Full color inkjet; fixed head design; high capacity ink tanks;
automatic printhead cleaning and capping service station.
DIMENSIONS
24" W x 20.5" H x 20" D x (609.6 mm x 520.7 mm x 508 mm)
WEIGHT
90 lbs. (40.9 kg)
ELECTRICAL
100-240 VAC, 50/60 Hz
FUSE
2.5A, 250V, slow blow
All Specifications Subject To Change Without Notice
Operation should take place under the following conditions:
- At temperatures between +15°C and +35°C (59 °F to 95 °F).
- At a relative air humidity between 20% and 80%, non-condensing.
- At an atmospheric pressure between 70 kPa and 105 kPa.
Exposure to conditions that are not permissible may lead to damage which is not externally visible.
Allow the printer, printhead and ink tanks to acclimate to ambient temperature before using the printer
