Pro-face GP-2300T User Manual

3.2 Preparation
Requirements for
receiving screen data
from GP-2300 series.
*1
GP-2300T/2300L/2301S/2301L:
PC in which GP-PRO/PBIII for Windows V6.0 or later is
installed. *2
GP-2300S/2301T:
PC in which GP-PRO/PBIII for Windows C-Package02 V6.3 or
later is installed. *2
Transfer Cable
(The following three types of cables are available.)
・ GPW-CB02 (D-sub 9 pin to PC)
・ GPW-CB03 (USB to PC) *3
・ GP430-CU02-M or GPW-SET (D-sub 25 pin to PC)
* Possible to send/receive a screen via Ethernet (for
GP-2300T/S/L only) or with a CF card.
Requirements for
converting screen
data of GP-2300
series and
transferring the
converted data to
GP-4301T/TW
PC in which GP-Pro EX Ver.3.0 or later is installed
Transfer Cable
(The following three types of cables are available.)
・ A USB transfer cable (model: CA3-USBCB-01)
・ A USB data-transfer cable (model: ZC9USCBMB1)
・ A commercial USB cable (USB Type A/mini B)
* Possible to send/receive a screen with a SD card
(GP-4301TW only), a USB storage device or via Ethernet.
*1: This step is required if screen data is saved only in the GP unit, not in any other device
*2: Please use the same version or later as or than that of the software used during creating screens on
GP-2300 series. If you don’t know the version, we recommend you to use the newest version. The
newest version is GP-PRO/PBIII for Windows C-Package03 (SP2) V7.29. Those who have
GP-PRO/PBIII for Windows C-Package03 V7.0 can download it from our web site called [OtasukePro!]
(http://www.pro-face.com/otasuke/download/update/
).
*3: GPW-CB03 is supported by GP-PRO/PBIII for Windows C-Package02 (SP2) V6.23 or later. You need to
install a driver from [Download] on our Web site called [OtasukePro!]
(http://www.pro-face.com/otasuke/download/driver
).
26/59
