4.6.1 When using a RS-232C connection cable
GP-2300 series System Configur
ation (connecting to
COM1
)
GP-4301T/TW System Configur
ation (connecting to
COM1
)
T
o replace GP-2300 series with GP-4301T/TW
, prepare the following item.
Product Name
Model
RS-232C 9-pin/25-pin Conversion Cable (20cm)
CA3-CBLCB
T232-01
52/59
51
53
