Resin Boss Type
Installation procedure
NOTICE
PANEL UNSTEADY WHEN UNSECURED
z Keep GP unit stabilized in the panel-cut while you are installing or removing the
screw fasteners.
Failure to follow the instruction can result in equipment damage.
Step Procedure Details
1 Follow the standard mount or flat mount panel cut dimensions to perform suf-
ficient tests in advance with designs that meet the following conditions, confirm
the safety of the system, and then mold the resin plate.
'
(
&
&
%
%
$
$
Standard mount Flat mount
To Next Page
