Key No. Qty. Description Key No. Qty. Description
PART LIST
Model No. PFTL44920.0 R0720A
1 2 3/8" x 2 1/4" Screw
2 4 M8 x 50mm Screw
3 2 3/8" x 3/4" Screw
4 5 Hood Clip
5 24 M4.2 x 19mm Screw
6 2 #8 x 3/8" Screw
7 4 M8 Star Washer
8 2 M8 x 35mm Screw
9 4 M4.2 x 13mm Washer Head Screw
10 2 M4.2 x 25mm Screw
11 2 #8 x 5/8" Screw
12 4 M4.2 x 19mm Tek Screw
13 7 M4.2 x 19mm Washer Head Screw
14 11 M4 x 10mm Screw
15 4 M8 x 30mm Screw
16 4 M4.2 x 13mm Belt Guide Screw
17 2 M6 x 70mm Screw
18 2 1/4" x 3/8" Screw
19 1 M8 x 102mm Bolt
20 2 #10 x 3/4" Screw
21 2 #10 Star Washer
22 2 M8 x 20mm Bolt
23 2 3/8" x 2" Bolt
24 2 M8 x 40mm Screw
25 2 M10 x 58mm Bolt
26 2 M10 x 58mm Screw
27 1 3/8" x 1 1/4" Bolt
28 1 3/8" x 2" Hex Head Bolt
29 32 #8 x 3/4" Screw
30 1 M6 x 60mm Bolt
31 2 1/4" Flat Washer
32 2 M8.4 Star Washer
33 4 M6 Star Washer
34 14 Small Washer
35 1 M8 Jam Nut
36 4 M10 Washer
37 2 M8 Flange Nut
38 4 M8 Nut
39 4 3/8" Jam Nut
40 1 M6 Nut
41 1 Latch Plate Spacer
42 2 M8 Weld Nut
43 2 M10 Nut
44 1 Left Foot Rail
45 1 Right Foot Rail
46 1 Warning Decal
47 1 Latch Plate
48 1 Walking Platform
49 1 Walking Belt
50 2 Platform Cushion
51 2 Belt Guide
52 1 Drive Roller/Pulley
53 1 Drive Belt
54 1 Controller
55 1 Controller Clamp
56 1 Electronics Bracket
57 1 Frame
58 1 Drive Motor
59 1 Drive Motor Bracket
60 1 Right Rear Foot
61 1 Left Rear Foot
62 1 Hood
63 4 Frame Spacer
64 1 Incline Motor
65 1 Lift Frame
66 4 Frame Bushing
67 1 Power Cord
68 1 Power Cord grommet
69 1 Power Switch
70 1 Belly Pan
71 1 Left Handrail Top
72 1 Right Handrail Top
73 1 Left Handrail Bottom
74 1 Right Handrail Bottom
75 2 Ground Wire
76 1 Console Frame
77 1 Crossbar
78 1 Upright Wire Harness
79 1 Latch Assembly
80 1 Left Upright
81 1 Right Upright
82 1 Left Outer Upright Cover
83 1 Left Inner Upright Cover
84 1 Right Inner Upright Cover
85 1 Right Outer Upright Cover
86 2 Base Cap
87 4 Round Base Pad
88 1 Grommet
89 1 Key/Clip
90 1 Base
91 2 Caution Decal
92 2 Cable Tie
93 2 Wheel
94 1 Left Tray
95 1 Right Tray
96 1 Console Base
97 1 Console
* – User’s Manual
Note: Specifications are subject to change without notice. For information about ordering replacement parts, see
the back cover of this manual. *These parts are not illustrated.
