Locate the Reed Switch (54) and the Magnet (42)
on the left side of the Pulley (44). Turn the Pulley
u
ntil the Magnet is aligned with the Reed Switch.
Make sure that the gap between the Magnet and
t
he Reed Switch is about 3 mm.
I
f necessary,
loosen the M4.2 x 19mm Screw (1), move the Reed
Switch slightly, and then retighten the Screw.
Reattach the Hood (not shown), and run the tread-
mill for a few minutes to check for a correct speed
reading.
PROBLEM: The console displays remain lit when you remove the key from the console
SOLUTION: a. The console features a display demo mode, designed to be used if the treadmill is displayed in a
store. If the displays remain lit when you remove the key, the demo mode is turned on. To turn off
the demo mode, hold down the Stop button for a few seconds. If the displays are still lit, see THE
INFORMATION MODE on page 19 to turn off the demo mode.
PROBLEM: The walking belt slows when walked on
SOLUTION:
a. If an extension cord is needed, use only a 3-conductor, 14-gauge (1mm
2
) cord that is no longer
than 1.5 m.
b. If the walking belt is overtightened, treadmill perfor-
mance may decrease and the walking belt may be-
come damaged. Remove the key and
UNPLUG
THE POWER CORD. Using the hex key, turn both
rear roller bolts counterclockwise, 1/4 of a turn.
When the walking belt is properly tightened, you
should be able to lift each edge of the walking belt 5
to 7 cm off the walking platform. Be careful to keep
the walking belt centered. Then, plug in the power
cord, insert the key, and run the treadmill for a few
minutes. Repeat until the walking belt is properly
tightened.
c. If the walking belt still slows when walked on, see the front cover of this manual.
T
op
V
iew
42
1
54
3 mm
44
Rear Roller Bolts
5 to 7 cm
b
23
