13
10. Insert the Upright Wire (81) through one looped
tie (I), and insert the console wire (J) through the
other tie on the console assembly (F).
Connect the Upright Wire (81) to the con-
sole wire (J). The connectors should slide
together easily and snap into place. If they
do not, turn one connector and try again. Next,
remove the wire tie (A) from the Upright Wire.
Insert the excess Wire (81, J) into the console
assembly (F). Then, pull the ties (I) tight around
the Upright Wire (81) and the console wire (J),
and cut off the ends of the ties.
10
I
I
A
J
F
81
11. Tighten two #8 x 1" Screws (31) into the console
assembly (F).
Then, fi rmly tighten the four 1/4" x 1/2"
Screws (12) (only one side is shown).
11
31
F
12
