8
2. Make sure that the power cord is unplugged.
Pivot the Right and Left Rear Feet (66, 67) down
from the shipping position as shown.
With the help of a second person, carefully raise
the Left and Right Uprights (94, 95) to the verti-
cal position.
IMPORTANT: Do not use the treadmill
with the Rear Feet (66, 67) in the shipping
position.
94
2
95
3
4
83
95
1
67
66
3. Tighten a 3/8" x 2 1/4" Screw (1) and a
3/8" x 3/4" Screw (4) into the Right Upright
(95) and the Base (83) as shown; do not fully
tighten the Screws yet.
Repeat this step on the left side (not shown).
Then, tighten all four Screws (1, 4).
To Next Page
