Function Description Setting options Factory settings
DIRECTION Adjustment of absolute value encoder (AWG) only with special assembly of the
operator
R: Standard assembly
(Clockwise rotational direction / increasing AWG values during opening
run)
L: Special assembly
(Anti-clockwise rotational direction / increasing AWG values during
opening run)
R – L R
REVERS-
POINT
Reversing switch-off point before the CLOSED end position is reached.
After travelling beyond this point, the door is stopped if the closing edge safety device
or the photocell is triggered, but no reversing takes place. The reversing point must
not lie more than 5 cm over the lower end position.
10 – 250 inc. 50
POWER Automatic power monitoring (rotational speed monitoring)
Error message if the door is unable to move freely or is obstructed.
Setting the sensitivity for the OPEN direction of travel.
A reading giving the power value (rotational speed) is shown during opening runs.
If the power monitoring facility is activated, a value must be set that is lower than the
lowest value displayed during door opening.
The larger the difference compared to the lowest value displayed, the less sensitively
the power monitoring reacts.
The power monitoring facility is only activated if a value > 0 has been set.
0 – 999 inc. 10
AUTO LEVEL Automatic adjustment of lower end switch-off point to a change in the ground condi-
tions (setting the steel cables on the sectional door).
ON: Function active
OFF: Function not active
Please note:
If the closing edge is triggered four times in a row when it is near the CLOSED end
position, the control recognises a change in the ground conditions.
The lower end switch-off point is then set four impulses further upwards.
ON – OFF OFF
P/E BARR
POINT
The signal from the photocell (X4 / 1-4) is not evaluated between the CLOSED end
position and the P/E BARR POINT. Setting is done in increments, starting from the
CLOSED end position.
Please note:
This function serves to suppress the signal from the photocell in the lower range, in
order to prevent faults, such as in the spiral cable.
0 – 999 inc. 300
PRESS/REL Choose between impulse and manual operation, with or without evaluation of closing
edge safety device (CESD) and photocell system (LB).
MOD1: Impulse operation for OPEN + CLOSE with SKS and LB
MOD2: Manual operation for OPEN + CLOSE with SKS and LB
MOD3: Manual operation for CLOSE with SKS and LB
MOD4: Impulse operation for OPEN + CLOSE with light curtain
If the light curtain is interrupted in the OPEN end position, the open time
(if programmed) will restart.
MOD5: Impulse operation for OPEN + CLOSE with light curtain
If the light curtain is interrupted in the OPEN end position, the open time
(if programmed) will not restart but will continue to elapse.
MOD1 – MOD5 MOD1
